Type K Thermocouple Compensation Cable Construction
| Conductor | Flexible (16x0,32mm) |
| Cross-sectional area: 1,30mm2 | |
| Materials: | |
| (+) Fe (Iron) | |
| (-) Copper - Nickel (Constantan) | |
| Insulation | PVC (Polyvinyl chloride) |
| Diameter: 2,60 mm Aprox. | |
| Identification | (+) Green |
| (-) White | |
| Assembly | Conductors in parallel |
| Outer sheath | PVC (Polyvinyl chloride) |
| Colour: Green |
Type K Thermocouple Compensation Cable Application
Thermocouple compensation cables are used to connect thermocouple sensors to remote connection points such as control cabinets, instruments, regulators, etc., so that sensor signals can be transmitted over long distances without signal loss and connected to processing units.
Type K Thermocouple Compensation Cable Technical characteristics
| Operating Tª | -5°C + 70°C |
| Conductor resistance | Aprox. 490 Ohm/Km (loop) a 20°C |
| Tolerance (e.m.f) | Class 2: |
| ±100 µV ( ±2,5°C) | |
| Test Voltage | 1000 Vcc (conductor-conductor) |
| Insulation resistance | >20 MOhm (20°C) |
Type K Thermocouple Compensation Cable Standards
- Reference standards IEC 60584
- Flame Retardant UNE-EN 60332-1 (IEC 60332-1)
Type K Thermocouple Compensation Cable Specification
| NxS (mm2) | Dimensiones (mm) | Weight (kg/km) |
|---|---|---|
| 2x1,30 | 6,80 x 4,20 | 57 |
